ModUnits

Mod Units Translation.csv

List of fields used in translation.csv for Units

Units Translation

Mod Units/Bots

JSON

{
  "units": [
    {
      "pickUpTime": 0.5,
      "dropOffTime": 0.5,
      "utilityDropOff2Time": 0.7,
      "utilityDropOff1Time": 0.5,
      "utilityDropOff0Time": 0.3,
      "blockedCheckInterval": 5.0,
      "typeId": 0, // unit-bot ID
      "componentInfos": [
        {
          "$type": "EntityLocomotorDataInfo, Game",
          "maxSpeed": 0.05,
          "accelerationFactor": 1.0, //??
          "typeId": 6 // = unit-bit
        }
      ]
    },
}

Existing Unit values

Icon

None

3D Models

None (tbd)

Bot Materials

Main Material

The material of bots can be changed using an image file, bot_material_main.png in a mod.
The file should be 512x512 pixels and consist of 16 128x128 pixel subsections, 8 of which are used for each colour of the Colony Ship possibilities.
Each sub-section is further divided into 16 32x32 pixel squares representing the colour for parts of the bots' materials.
Example File:

Sub-section mapping:

1. - Bot Wheels Outer (all Bots that have wheels - i.e. most)
2. - Bot Wheels Inner (all Bots that have wheels - i.e. most), Shovel (Forester), Hammer + Wrench (Blacksmith?) Helmet Strap (RepairBot? +?+?)
3. - Main Bot Material
4. - Unused?
5. - Mallets, Picks, FishHook, Threshers, AxeHead, Exhaust Pipes
6. - Cap Trim (TrainBot), HardHat (BuildBot)
7. - Apron (BakerBot)
8. - FishingPole (FisherBot), SeedPile(TreeBot), BackCoil (RoadBot, BuildBot, RepairBot, ShipwrihtBot)
9. - FishingLine (FisherBot), HardHat Lamp (Shaft Miner Bot)
10. - Cap (TreeBot)
11. - Apron (Blacksmith, TrainBot), Cap (TrainBot)
12. - Unused
13. - Unused
14. - Unused
15. - Unused
16. - Main Colony Colour + Mask Trim, Gloves, Many Caps, etc. (Swaps out to appropriate main section when Colony Color is changed in game).

Color Ramp

bot_material_ramp.png should be a 128 x 128 pixel sized file for the color ramp.
Example bot_material_ramp file.
